Laboratory scale GRAM TG

electroniclboz

Overview
High-capacity precision balance combining weighing, counting and formulation functions with configurable programs and GLP-capable data output. Suitable for laboratory, quality-control and production workflows where repeatability and documentation are required.

Key capabilities

• Formulation with recipe memory: supports manual and stored formulations; recipes with multiple components can be created, saved, recalled and adjusted to enable controlled, repeatable formulation processes.
• Piece counting and percentage weighing: integrated functions for inventory tasks, comparative measurements and process control.
• Configurable filters and stability settings: multiple filter levels, auto-zero options and stability modes to adapt to stable or disturbed environments.
• GLP-compatible data output: date- and time-stamped output via RS-232C for structured documentation and traceable reporting to a PC or printer.
• Under-hook weighing capability: integrated under-hook option for suspended measurements (density determination, oversized samples, etc.).

Design & build
Robust housing with a large stainless-steel weighing pan and reinforced structure; available plate sizes for different capacity classes. External calibration supported; graphic display and intuitive menu structure for efficient operation.

Capacity & accuracy highlights
High-capacity balance family with resolutions from 0.01 g up to 0.1 g and capacities ranging up to 32 kg, targeting applications that combine standard weighing, formulation, counting and documentation tasks.

Connectivity
RS-232C interface for data output and integration.

Technical specifications

• Model name: GRAM TG
• Capacity range: 12.1 kg up to 32 kg
• Resolution: From 0.01 g up to 0.1 g
• Trade approval: No
• Tare memories: No
• Weighing units: g, ct, oz, lb, gr, tl, mm
• Weighing filters: No (configurable filters and stability settings available in operation)
• Limits function: No
• Piece counting: Yes (integrated function)
• Connectivity: RS-232C (GLP-compatible date- and time-stamped data output)
• Material / Construction: Reinforced structure and weighing platform; robust housing with large stainless-steel pan (varies by configuration)
• Plate dimensions: 175 x 195 mm up to 320 x 220 mm (depending on capacity)
• IP protection: N/A
• Additional functions: Formulation (recipe memory), percentage weighing, under-hook weighing option, external calibration, adjustable filters and stability settings
