Vortex pump MTBE serieswaterelectricstationary
Add to favorites
Compare this product
Characteristics
- Technology
- vortex
- Fluid
- water
- Operation
- electric
- Mobility
- stationary
- Domain
- industrial, for machine tools
- Applications
- recycling
- Material
- cast iron
- Other characteristics
- close-coupled, central aspiration
- Flow
Max.: 90 m³/h
(3,178.32 ft³/h)Min.: 0 m³/h
(0 ft³/h)- Pressure
Max.: 16 bar
(232.06 psi)Min.: 0 bar
(0 psi)- Head
Max.: 48 m
(157'05" )Min.: 0 m
(0'00" )- Power
3 kW, 5.5 kW, 7.5 kW, 15 kW
(4.08 hp, 7.48 hp, 10.2 hp, 20.39 hp)- Fluid temperature
Max.: 90 °C
(194 °F)Min.: 0 °C
(32 °F)
Description
Close coupled End Suction pump with semi-open Vortex impeller with MGE motor
The MTB machine tool pumps are single-stage centrifugal pumps with axial suction port and radial discharge port. The pump is directly coupled with a totally enclosed fan-cooled standard motor. Main dimensions are according to IEC and DIN standards.
The MTB pumps are designed specifically for the transfer of liquids containing solid particles in industrial machine tool applications. Typical applications include:
machining centres
cooling units
grinding machines
lathes
washing devices.
