Roll coating machine SC-MP150
for paper

roll coating machine
roll coating machine
roll coating machine
Add to favorites
Compare this product


Treated material
for paper


Squeeze Roll Coater Type SC-MP150, Mineral Paper Coating Machine SC-MP150 mineral paper coating machine applies water-based coatings on the surface of mineral paper, it is widely used in production of printings and paper products, such as decorative wallpaper, packaging carton, cards, labels and tags, etc. The coating process can enhance the surface smoothness of mineral paper. Considering that the mineral paper is weak in tension and easy to be torn, so this mineral paper coating machine is designed with low operation speed. Specifications Machine speed: 150m/min Coating method: anilox roll, coating on both front and back sides of web, once on each side. Coating substrate: LLDPE film, thickness: 100-250μm Coating thickness: dry adhesive about 10-50μm Tension range: 40-400N/full width Configurations Unwind unit 1. Reversible independent turret unwinding with dual-shaft double working positions. 2. Edge position control (EPC) for automatic web guiding. Coating unit 1. Gravure coating and cylinder coating methods can be used in combination according to the actual needs of the process. 2. Applicator roll is driven independently by servo motor, and is running synchronously with the motor for laminating by means of PLC control. 3. Glue spreading is cycled automatically. Calendering and cooling unit 1. Calender roll has a hard chrome plated surface, and equipped with steel back-up roll. 2. Cooling roll is made of hard chrome plated steel, the cooling method of which is circulating water cooling. Rewind unit 1. Reversible independent turret rewinding with dual-shaft double working positions.
