- Guangxi Liugong Machinery Co., Ltd.
Rigid dump truck DW90Adieseldiesel enginemining and quarrying
Add to favorites
Compare this product
Characteristics
- Chassis
- rigid
- Motor type
- diesel, diesel engine
- Applications
- mining and quarrying, for quarries
- Payload
Max.: 60,000 kg
(132,277.36 lb)Min.: 55,000 kg
(121,254.24 lb)- Motor power
Max.: 382 kW
(519.38 hp)Min.: 306 kW
(416.04 hp)
Description
Key specifications
Industries
Product highlights
DW90A — Manual (specifications table)
DW90A — Automatic (specifications table)
Notes
For reference only.
Technical specifications
- Rated power: 306–382 kW (variant-dependent)
- Rated operating load / Rated load: 55,000–59,000 kg / 60,000 kg
- Body capacity (heaped): 36/38 m³; struck: 30/32 m³
- Operating weight: 31,000 kg
- Gross machine weight: 91,000 kg
Industries
- Mining
- Quarrying
Product highlights
- Full-hydraulic steering system that reduces operator effort
- Lifting system with full-time power take-off to simplify cycles and increase productivity
- Optimized center of gravity for improved stability on job sites
- Spacious, low-noise cab with wide visibility
- Powertrain supplied by world-class component manufacturers
- Integrated brake and alarm systems
- Leaf-spring suspension for effective shock absorption
DW90A — Manual (specifications table)
- Operating weight: 31,000 kg
- Gross machine weight: 91,000 kg
- Heaped capacity (SAE 2:1): 36/38 m³
- Emission regulation: Tier 3 / Stage III
- Transmission model: 7DS220A
- Maximum travel speed: 36 km/h
- Tire: 14.00R25
- Rated load: 60,000 kg
- Struck capacity: 30/32 m³
- Engine model: YC6K480
- Rated power: 353 kW (473 hp) @ 1900 rpm
- Type: Manual
- Dimensions (L x W x H): 5,830 x 3,140 x 1,790 mm
DW90A — Automatic (specifications table)
- Operating weight: 31,000 kg
- Gross machine weight: 91,000 kg
- Heaped capacity (SAE 2:1): 36/38 m³
- Emission regulation: Tier 3 / Stage III
- Transmission model: FC6A250 / Allison 4800
- Maximum travel speed: 37 km/h
- Tire: 14.00R25
- Rated load: 60,000 kg
- Struck capacity: 30/32 m³
- Engine model: YC6K520
- Rated power: 382 kW (512 hp) @ 1900 rpm
- Type: Automatic
- Dimensions (L x W x H): 6,370 x 3,140 x 1,680 mm
Notes
For reference only.
Technical specifications
- Model: DW90A
- Rated power range: 306–382 kW (353 kW manual; 382 kW automatic)
- Rated operating load / Rated load: 55,000–59,000 kg / 60,000 kg
- Body / Heaped capacity: 30–38 m³ (heaped 36/38 m³)
- Struck capacity: 30/32 m³
- Operating weight: 31,000 kg
- Gross machine weight: 91,000 kg
- Engine models: YC6K480 (Manual), YC6K520 (Automatic)
- Transmission models: 7DS220A (Manual), FC6A250 / Allison 4800 (Automatic)
- Maximum travel speed: 36 km/h (Manual), 37 km/h (Automatic)
- Tire: 14.00R25
- Emission regulation: Tier 3 / Stage III
- Dimensions: Manual 5,830 x 3,140 x 1,790 mm; Automatic 6,370 x 3,140 x 1,680 mm
