LCD panel PC WAR-070C-SN00

7"1024 x 600ARM® Cortex™ A7 Quad Core

Basic parameters CPU：Quad-core Cortex®-A7 architecture，frequency 1.2GHz Memory：1GB DDR3 EMMC：8GB Display screen Size：7 inch Resolution：1024×600 Wide-temperature type，16000k colors or 24 true colors LED backlight：lifetime > 25000 hours Touch screen Capacitance touch screen Hardware interface 4 channel 3-wire RS-232 serial port（COM1,COM2,COM3,COM4）. 1 channel RS-485（COM4）multiplex as RS-232 (COM4) . 1 channel USB device interface, support ADB connect to PC to exchange data and debug application. 2 channel USB Host interface，support usual USB device such as mouse, keyboard, U disk ,etc. 1 channel 100M Ethernet interface. 1 channel SD/MMC slot, support TF /MMC card. 1 channel 3.5mm audio MIC interface. 1 channel 3.5mm audio HPC interface. 1 channel power amplifier interface (8Ω/3w). 1 channel SIM card interface . Six buttons: (1x Power, 1x Home, 2x Volume,1x User , 1x Reset ). 1 channel CAN interface.（optional）. 1 channel 4G module & interface . （optional） 1 channel WIFI module .（optional） 1 channel EDG3.5-3P DC 12V~24V，industrial power solution，higher reliability. Bluetooth ,GPS .（optional） OS Android 5.1 Defend degree / Working environment power：DC 12V-24V （24V as recommendation) working temperature：-10~60℃ storage temperature：-20~80℃ working humidity：10～90%RH Size No shell Size：202x113x20.6 （mm）
