- Hydraulics - Pneumatics
- Pump
- Venturi vacuum pump
- Gücüm Pompa Makina Sanayi Tic. A.S.
Venturi vacuum pump GMPT 520/400lubricatedsingle-stagesuction
Add to favorites
Compare this product
Characteristics
- Technology
- Venturi
- Lubrication
- lubricated
- Number of stages
- single-stage
- Applications
- suction, liquids
- Other characteristics
- stainless steel, low energy consumption
- Ultimate vacuum
Min.: 33 mbar
(0.48 psi)Max.: 400 mbar
(5.8 psi)- Flow rate
1,600 m³/h, 1,900 m³/h, 2,100 m³/h
(56,503.47 ft³/h, 67,097.87 ft³/h, 74,160.8 ft³/h)- Power
55 kW
(74.78 hp)- Operating temperature
70 °C, 100 °C
(158 °F, 212 °F)- Length
2,680 mm
(106 in)- Width
745 mm
(29.33 in)- Height
1,330 mm
(52.36 in)- Noise level
85 dB
- Weight
1,020 kg, 1,980 kg
(2,248.72 lb, 4,365.15 lb)
Description
High suction capacity, low energy Consumption.
Plates are stainless steel.
Safe and efficient operation.
Able to pump every kind of gases and vapors.
Works quiet and reduced vibration.
No need to lubrication.
Low operation and investment cost.
Minimum maintenance with high efficiently.
No metallic contact of the rotating parts.
Able to use every medium with wide material alternatives.
Able to pump less liquid with gases.
Provide 0 leakproofing with mechanical seal.
