- Hydraulics - Pneumatics
- Pipe, Tube and Fitting
- Hydraulic hose
- Handanshi Kangmai Hydraulic Equipment Co. Ltd.
Hydraulic hose SEA 100 R1rubberhigh-pressurewear-resistant
Add to favorites
Compare this product
Characteristics
- Use
- hydraulic
- Material
- rubber
- Applications
- high-pressure
- Other characteristics
- wear-resistant, flexible
- Inner diameter
Min.: 4.8 mm
(0.189 in)Max.: 50.8 mm
(2 in)- Outer diameter
Min.: 11.8 mm
(0.465 in)Max.: 64 mm
(2.52 in)- Pressure
Min.: 580 psi
Max.: 3,630 psi
- Temperature
Min.: -40 °C
(-40 °F)Max.: 100 °C
(212 °F)
Description
SAE100R1 AT/DIN EN 853 1SN
Inner tube: Oil resistant synthetic rubber.
Reiforcement: one high tensile steel wire braid.
Cover: abrasion and weather resistant synthetic rubber.
Temperature range: -40°C~100°C
Catalogs
No catalogs are available for this product.
