Hydraulic actuator CYT

hydro-pneumaticlinearpiston

Product name
Nitrogen-charged hydraulic operating mechanism CYT series

Category
Components & processing support - Mechanisms

Product description
The CYT series nitrogen-charged hydraulic operating mechanisms are self-developed units covering operating energies from 6 kJ to 28 kJ and suitable for voltage levels from 252 kV to 1100 kV. They provide fast actuation, sensitive response and high output energy with strong reliability. Modular design minimizes external piping, resulting in a compact and tidy assembly. Nitrogen energy storage ensures output characteristics that match circuit breaker load profiles; make-break timing is easily adjustable. A built-in safety valve protects the hydraulic system from overpressure. Suitable for domestic and international projects, indoor and outdoor installations, and offshore wind applications.

Features / Advantages

• Operating energy range: 6 kJ to 28 kJ.
• Applicable voltage levels: 252 kV to 1100 kV.
• Fast actuation, sensitive response, high output energy and high reliability.
• Modular design with minimal external piping; compact and neat construction.
• Nitrogen energy storage with output characteristics matched to circuit breaker loads.
• Easily adjustable make-break (close-open) timing.
• Built-in safety valve to prevent hydraulic overpressure.
• Wide applicability: domestic/international, indoor/outdoor, offshore wind.

Technical specifications

• Series: CYT
• Operating energy: 6 kJ to 28 kJ
• Applicable voltage levels: 252 kV to 1100 kV
• Design features: modular design, minimal external piping, built-in safety valve
• Applicable environments: indoor, outdoor, offshore wind farms and international projects
