Telescopic loading spout NZOF600DH

Telescopic spouts type NZOF600DH are used for dust free loading of dry, dusty bulk solids into stockpiles. OPERATIONAL QUALITIES max. loading rate up to 1000 m3/h particle size 0-100 mm connection flange DN 600 internal dust collector: dedusting volume 5.000 m3/h, fan 7.5 kW, filter area 59.9 m2, filter elements: cartridges, 12 pcs standard operational temperature -20 °C/+80 °C motor drive 5.5-9.2 kW loading conduit consisting of internal telescopic tubes and external bellows DESIGN electric winch with limit switch rope switch level sensor - rotary (2 pcs), tilt type (4 pcs) skirted outlet Additional features electric control box design for ATEX design for non-standard temperature (-40 °C/+150 °C)
