Air filter H-Mat 15 Pluswatercartridgepressure
Add to favorites
Compare this product
Characteristics
- Designed for
- air, water
- Filtration element
- cartridge
- Filtration method
- pressure
- Fluid specification
- condensate
- Other characteristics
- high-efficiency
- Flow
Min.: 1.2 m³/min
(42.378 ft³/min)Max.: 100 m³/min
(3,531.467 ft³/min)
Description
More efficiency with pre ko-streamingfilter higher capacity and longer filter use,
1, Chamber for expansion and de-airation with charcoal filter to exhaust air
2, Condensate feed is possible both under pressure and pressureless
3, Collecting chamber
4, Preko-streamingfilter
5, Settling and Flotation Chamber
6, End stage filter
7, Water discharge
8, Test valve
9, Oil-collect tank with overflow safe-guard
10, Test set, check-glass and oil test paper
11, Document depertment
12, Optical level control as standard
13, Heater (optional)
