Wedge welding machine ComOn 3

for plasticsfor thermoplastics230V single phase

The wedge welding machine ComOn 3 integrates data recording and weld-parameter monitoring for reproducible seams and simplified traceability. Designed for industrial applications, it combines high welding performance with app connectivity for on-site reporting and GPS-tagged logs.

Key features

• Integrated recording of all welding parameters to ensure reproducible weld seams.
• Generates welding logs compliant with common standards and regulations.
• Records welding data and creates reports via the app, including GPS location.
• High welding speed and consistent joint quality.
• Weldable HD-PE thickness: 1.0–3.0 mm.
• Optional kit available for preheating/drying with a handheld device.

Materials / material thickness

• Material types: PE-LD, PE-HD, PP, ECB, EVA, TPO.
• Wedge length: 100 / 80 mm.

Technical specifications

• Voltage [V]: 230
• Frequency [Hz]: 50/60
• Power [W]: 2100 / 1700
• Temperature [°C]: 20–420
• Speed [m/min]: 5 / 10
• Joining force [N]: 1500
• Material thickness (indicative) HD-PE: 1.0–3.0 mm (depending on material)
• Dimensions L x W x H [mm]: 450 x 280 x 350
• Weight [kg]: 18.5
• Seam measurement with test channel: 15-15-15
• Conformity marking: CE
• Protection class: I
• Wedge length: 100 / 80 mm
• Applicable materials: PE-LD, PE-HD, PP, ECB, EVA, TPO
