Compact zero-point clamping unit M-96x96(8051A)S

for machine toolshigh-precisionpneumatic

Product Overview
Compact zero-point pneumatic clamping bridge engineered for CNC automation and rapid fixture exchange. Designed to integrate with 96 mm zero-point systems, this 1-station bridge accepts pull studs (M-96x96PS) for fast installation and repeatable positioning, delivering high positioning accuracy and process reliability to improve machining throughput and repeatability.

Highlights / Features

• Integration-ready for automated CNC workholding and quick pallet or fixture changes
• Compatible with 96 mm zero-point pneumatic clamping systems
• Uses pull studs M-96x96PS for fast engagement and repeatable positioning
• High positioning accuracy and process reliability to increase machining efficiency
• Compact footprint suitable for single-station automation cells

Visuals
Includes product image and technical-dimension drawing showing the bridge, pull-stud locations and mounting-hole pattern for seamless integration into 96 mm zero-point automation systems.

Specifications (table)
Model: M-96x96(8051A)S
L x W x H (mm): 450 x 156 x 51
Pull Studs: M-96x96PS
Mounting Holes: 400 x 90
Weight (kg): 19.7

Technical specifications

• Model: M-96x96(8051A)S
• Overall dimensions (L x W x H): 450 x 156 x 51 mm
• Compatible pull studs: M-96x96PS
• Mounting hole pattern: 400 x 90 mm
• Weight: 19.7 kg
• Units: mm for dimensional data
