Poppet pneumatic directional control valve VDP series
pneumatically-operatedelectrically-operated3-way

poppet pneumatic directional control valve
poppet pneumatic directional control valve
poppet pneumatic directional control valve
poppet pneumatic directional control valve
poppet pneumatic directional control valve
Add to favorites
Compare this product


Characteristics

Type
poppet
Actuating method
pneumatically-operated, electrically-operated
Ports/positions
3-way, 2-way
Other characteristics
aluminum, compact, brass, stainless steel, steel
Operating pressure

100 mbar
(1 psi)

Description

Shifting the bulk solids flow in a down pipe, two or three ways, symmetric or asymmetric, section adaptable. • Simple assembly • Sturdy design • Low maintenance • Product temperature max.: 100°C • Max./min. ambient temperature: -10 °C ≤ T ≤ 50 °C • Solid to bulk data: powders and granules, medium hardness free flowing up to difficult flowing This is not an equipment according ATEX-directive 2014/34/EU, but in contact with product (inside) usable in the zones 20-21-22. Additional electrical parts must be approved for the chosen ATEX-zone. Switching during flowing product flow is only admissible in exceptional cases and after agreement of the manufacturer. Interrupt the product flow shortly before switching (e.g. lock using a slider, stop the conveyor device). It is not allowed to switch the flap in the non flowing product columne. It is not allowed to switch the flap, if in one exit the product is not flowing out.
