Precision boring head BHC
Add to favorites
Compare this product
Characteristics
- Options
- precision
- Diameter
10 mm
(0.39 in)
Description
Overview
The BHC multi-spindle boring unit by HSD is a modular drilling/boring solution for machining wood and a wide range of industrial materials and metals. Available configurations support multiple vertical spindle counts and optional horizontal or blade modules.
Applications / Materials
Accessories
Technical sheet
Configuration (V=vertical spindles / H=horizontal / B=blade): 7÷42 / 0÷5 / 0
The BHC multi-spindle boring unit by HSD is a modular drilling/boring solution for machining wood and a wide range of industrial materials and metals. Available configurations support multiple vertical spindle counts and optional horizontal or blade modules.
Applications / Materials
- Wood
- Metals and other industrial materials
Accessories
- Solenoid valve pack, available in 10/12/16/18/22/26/28 positions (BHC line / BHZ line)
Technical sheet
Configuration (V=vertical spindles / H=horizontal / B=blade): 7÷42 / 0÷5 / 0
- Vertical spindles: max speed: 8000 RPM
- Vertical spindles: stroke: 60 mm
- Spindles: pitch: 32 mm
- Vertical spindles: connection: Ø10
- Horizontal spindles: not specified (-)
- Blade: not specified (-)
- Liquid cooling: Yes
- Lubrication: Automatic
- Electrovalve remote unit: Optional
- Weight: 125 kg
Catalogs
No catalogs are available for this product.
