Electro-hydraulic bending machine PB Series
for tubesCNCforming

electro-hydraulic bending machine
electro-hydraulic bending machine
electro-hydraulic bending machine
electro-hydraulic bending machine
Add to favorites
Compare this product


Characteristics

Operation
electro-hydraulic
Product handled
for tubes
Control
CNC
Associated function
forming

Description

Introduction Plate crimping press is widely used in LSAW pipe production. As a metal forming machine manufacturer in China, we supply PB series crimping press machines. They are designed to crimp both edges of metal plates to form a curvature radius of plate edges close to curvature radius of finished pipe. Generally, this type of plate crimping press is composed of C-frames, oil cylinder units, lower tool beam, transporting roller on frame, tool changing device, tools, tool moving device, pedestal, front and rear roller tables, electrical system, as well as hydraulic and lubrication systems. During the pre-bending process, plates are fed into upper and lower tools step by step after milling. The pressing force comes between the two tools of the crimping press machines. In order to make crimped edge curvature radius become very close to the curvature radius of finished pipe, tools position should be changed and adjusted several times. Usually two plate crimping press are set oppositely and synchronously pre-bend the plate laterally. It is suitable for the steel pipe with the maximum thickness of 40 mm.

VIDEO
