Concrete cutter CS 2512

Product overview
Used with the hydraulic unit PP 455 E, the Husqvarna CS 2512 is a compact, mobile wire saw designed for both small jobs and very large, deep cutting operations. It can be mounted on the ground or on walls and is suitable for cutting steel, concrete and other building materials.

Benefits

• Large net wire storage to reduce wire changes
• Flexible modular setup for vertical or horizontal positioning
• Easy transport and dismantling for site mobility
• Smooth, controlled cutting thanks to automatic pulley guidance

Key features

• Large wire magazine capacity enabling extended cuts without changing the wire
• Modular setup — can be positioned vertically or horizontally; motor detachable
• Collapsible handles and foldable guard; unit can be broken down into sections for transport
• Pulleys follow wire direction via ball-bearing rotation for smooth cutting
• Drive wheel on output side to prevent slack in the wire magazine
• Adjustable pressure valve for precise control of cutting and wire tension
• Suitable for large jobs such as foundations and bridge works
• Capable of cutting thick walls and creating precise corner openings
• Designed for deep sawing in confined spaces

Technical data (top specifications)
Wire speed (gear 2, max): 25 m/s
Output power with PP 455: 20 kW
Net wire storage capacity: 16 m
Weight (complete product w/o side packed articles): 150 kg

Technical characteristics / specifications

• Commercial designation: CS 2512
• Article description: WIRE SAW CS 2512 (Wiresaw)
• Article number: 965 15 62-01
• Compatibility: hydraulic unit PP 455 E
• Typical applications: ground or wall-mounted sawing in steel, concrete and other building materials; foundations, bridges, thick walls, confined spaces
