Electric self-propelled trailer SPMT

battery-poweredfor heavy loadshydraulic

Overview
INDUSTRIAL LIFT SPMTs provide an advanced solution for transporting complex loads on uneven ground. Thanks to their modular configuration and the possibility to combine axles, they ensure power, stability and maximum adaptability between individual modules. High-precision electronic steering and the axle compensation system allow smooth and safe maneuvering, even with loads that have a variable weight distribution or on imperfect surfaces.

Product details

• Configurable modular architecture, adaptable to the dimensional and functional specifications of the load
• Mechanical and hydraulic connection between modules through longitudinal and transversal coupling
• Hydraulic leveling system to ensure load stability
• Easy handling on rough or uneven surfaces
• Multifunction radio remote control for centralized real-time management of one or more modules
• Multidirectional electronic steering system, to ensure high precision and reduced maneuvering spaces
• Maintenance program with inspections and periodic checks
• Anti-corrosion surface treatment specifically designed for highly aggressive environments
• Real-time remote assistance via M2M system and global 4G connectivity
• High safety standards with control and monitoring devices

Technical specifications — key points
The chassis is made of structural steel and dimensioned to ensure rigidity under all load conditions; modular geometry allows mechanical coupling longitudinally and transversely. The engine compartment is tiltable to adapt to slopes and protect contact with the ground; engine and electrical panel are protected by lockable aluminum doors with monitoring indicators and double doors for enhanced safety. Electronic steering (DSC — Dynamic Steering Control) adapts movements to obstacles, providing precision in transport and maneuvering. Radio remote control with proportional controls manages all movements remotely for safe operations and enhanced visibility. Modules with 3, 4, 5 or 6 axle lines can be interconnected and synchronized to operate as a single platform for large/bulky loads. Router and M2M SIM installed in the electrical panel enable remote monitoring, diagnostics and intervention. Advanced electronic leveling and active hydraulic compensation systems ensure constant load balance on uneven surfaces, inclines, or with variable centre of gravity. Anchoring, lifting and towing points are integrated into the frame and dimensioned according to regulations to ensure reliability under all conditions.

Technical characteristics / specifications

• Modular architecture: individual modules combinable longitudinally and transversely
• Axle configurations: modules available with 3, 4, 5 or 6 axle lines (interconnectable)
• Steering: high-precision multidirectional electronic steering with Dynamic Steering Control (DSC)
• Leveling & compensation: hydraulic leveling system and active hydraulic compensation for stability optimization
• Remote control: multifunction radio remote with proportional controls for centralized real-time management
• Remote assistance & connectivity: M2M router and global 4G connectivity for diagnostics and remote monitoring
• Engine compartment: tiltable engine compartment with lockable aluminium doors and monitoring indicators
• Structure: structural steel chassis designed for high rigidity and modular coupling
• Surface treatment: anti-corrosion treatment for highly aggressive environments
• Maintenance: planned maintenance program with inspections and periodic checks
• Safety: integrated control and monitoring devices; anchoring, lifting and towing points dimensioned per regulations
• Electric version: available full-electric variant with low noise, low emissions and high efficiency suitable for indoor or low-emission areas
