Assembling tool tool balancer ZG2W0 series

tool managementfor hand toolswith safety lock

Overview
The Zero Gravity Air Balancer 2.0 from Ingersoll Rand is an air-powered load-balancing device designed to reduce operator effort, simplify installation and maintenance, and increase handling flexibility across industrial assembly and material-handling applications.

Features
Ergonomics:

• Redesigned ergonomic handle reduces operator effort while in float mode.
• Handle geometry and controls minimise fatigue and repetitive-stress risk for continuous use.

Simplicity:

• Plug-and-play design enables rapid installation with minimal technical training.
• Intuitive controls for quick safety and float adjustments.
• Windows GUI tool adds data run and cycle times for predictive maintenance planning.

Flexibility:

• Retrofit-capable to install on new or existing Ingersoll Rand Air Balancers.
• Seamless transition between handle and float modes to save cycle time.
• New 3-speed control system for finer operator control and process adaptation.

Model Specifications (table)
Model | Load Capacity (lb) | Top Mount | Weight
ZG2W01508000B | 150 | NO SUSPESNION | 55
ZG2W015080A1B | 150 | TROLLEY ZRA1 | 55
ZG2W015080A2B | 150 | TROLLEY ZRA2 | 55
ZG2W015080ATB | 150 | TROLLEY ZRAT | 55
ZG2W015080HMB | 150 | HOOK MOUNT | 55
ZG2W015080S2B | 150 | TROLLEY ZRS2 | 55
ZG2W02012000B | 200 | NO SUSPESNION | 68
ZG2W020120A1B | 200 | TROLLEY ZRA1 | 68
ZG2W020120A2B | 200 | TROLLEY ZRA2 | 68
ZG2W020120ATB | 200 | TROLLEY ZRAT | 68
ZG2W020120HMB | 200 | HOOK MOUNT | 68
ZG2W020120S2B | 200 | TROLLEY ZRS2 | 68
ZG2W020120S00B | 200 | NO SUSPESNION | 68
ZG2W020120SA1B | 200 | TROLLEY ZRA1 | 68
ZG2W020120SA2B | 200 | TROLLEY ZRA2 | 68
ZG2W020120SATB | 200 | TROLLEY ZRAT | 68
ZG2W020120SHMB | 200 | HOOK MOUNT | 68
ZG2W020120SS2B | 200 | TROLLEY ZRS2 | 68
ZG2W03508000B | 350 | NO SUSPESNION | 68
ZG2W035080A1B | 350 | TROLLEY ZRA1 | 68
ZG2W035080A2B | 350 | TROLLEY ZRA2 | 68
ZG2W035080ATB | 350 | TROLLEY ZRAT | 68
ZG2W035080HMB | 350 | HOOK MOUNT | 68
ZG2W035080S2B | 350 | TROLLEY ZRS2 | 68
ZG2W035080S00B | 350 | NO SUSPESNION | 68
ZG2W035080SA1B | 350 | TROLLEY ZRA1 | 68
ZG2W035080SA2B | 350 | TROLLEY ZRA2 | 68
ZG2W035080SATB | 350 | TROLLEY ZRAT | 68
ZG2W035080SHMB | 350 | HOOK MOUNT | 68
ZG2W035080SS2B | 350 | TROLLEY ZRS2 | 68
ZG2W05008000B | 500 | NO SUSPESNION | 115
ZG2W050080A1B | 500 | TROLLEY ZRA1 | 115
ZG2W050080A2B | 500 | TROLLEY ZRA2 | 115
ZG2W050080ATB | 500 | TROLLEY ZRAT | 115
ZG2W050080HMB | 500 | HOOK MOUNT | 115
ZG2W050080S2B | 500 | TROLLEY ZRS2 | 115
ZG2W050080S00B | 500 | NO SUSPESNION | 115
ZG2W050080SA1B | 500 | TROLLEY ZRA1 | 115
ZG2W050080SA2B | 500 | TROLLEY ZRA2 | 115
ZG2W050080SATB | 500 | TROLLEY ZRAT | 115
ZG2W050080SHMB | 500 | HOOK MOUNT | 115
ZG2W050080SS2B | 500 | TROLLEY ZRS2 | 115

Technical specifications

• Model name: Zero Gravity Air Balancer 2.0
• Brand: Ingersoll Rand
• Ergonomic handle to reduce operator effort and fatigue
• Plug-and-play design for fast setup and minimal training
• Windows GUI tool: run and cycle data for predictive maintenance
• 3-speed control system for improved operator control
• Retrofittable to existing Ingersoll Rand Air Balancers
• Available load capacities: 150 lb, 200 lb, 350 lb, 500 lb
• Top mount options: No Suspension, Trolley variants (ZRA1, ZRA2, ZRAT, ZRS2), Hook Mount
• Unit weight varies by model (see Model Specifications table above)
