Noise generator SM

magnetic fieldvoltagehorizontal

It stands out for its flexibility in handling applications as diverse and demanding as main power generation plants on cruise ships, adapting to the requirements of the combustion engine. Power up to 30 MVA and speed up to 300 rpm Direct drive, without gearbox SBN noise and shock requirements Technical data Rotor Type - Excited salient poles Frame Size - h ≥900 Power - Until 30 MVA Speed - Until 300 rpm Voltage - Until 6,600 V Temperature Rise Class - F or B Thermal Insulation Class - Up to class H Variable Speed - Yes Construction - Horizontal Protection Degree - Up to IP 56 Cooling - Upon request (except IC411) Bearings - Sleeve bearings Main Options - Lubrication groups, hydrostatic groups, special sensors (vibrations, temperature, speed, etc.) Characteristics Our equipment offers a set of key advantages that combine performance, reliability, and adaptability. Compact and robust design. High power density. Proven reliability and durability. First-class thermal insulation rating. Optimized efficiency. Versatility (design/configuration, operating modes, cooling method, etc.). Operation under the most severe conditions. Low maintenance requirement.
