Rotating beacon JR-L02

12VDCIP65recessed

Product overview Rotating Beacon JR-L02 is a visual and audible alarm accessory designed for telephone and emergency communication systems in industrial environments. It provides a rotating light signal combined with selectable alarm sounds to attract attention during incoming calls or alarm conditions. The unit features a weather-resistant ABS housing and IP65 protection for reliable operation in harsh conditions.

Features

• Rotating visual beacon combined with selectable audible alarm (A/B/C/D)
• High sound level: 100 dB
• Robust ABS housing with IP65 weather protection
• Available colours: Red, Yellow, Green (optional)
• Wide operating temperature range: -30°C to 70°C
• Low power consumption: 10W, DC12V

Technical specifications

• Operating voltage: DC12V
• Power frequency: 50Hz–60Hz
• Power consumption: 10W
• Alarm sounds: A/B/C/D (selectable)
• Sound level: 100 dB
• Warning mode: Rotating beacon on incoming call
• Housing material: ABS
• Colours: Red, Yellow, Green (optional)
• Protection rating: IP65
• Operating temperature: -30°C to 70°C
• Operating humidity: 10%–95% RH (non-condensing)

Applications

• Telephone accessories for industrial and mission-critical communication systems
• Emergency and alarm signalling in petrochemical, offshore, onshore, industrial and transport facilities

Compliance and additional information

• Suitable for panel or surface mounting in industrial installations
• Optional colour variants available; order configurable options as required
• Consult supplier for certifications, installation guidelines and maintenance
