Poppet check valve A0010 seriesfor watermalePTFE
Add to favorites
Compare this product
Characteristics
- Type
- poppet
- Fluid
- for water
- Body
- male
- Material
- PTFE, stainless steel
- Valve plug seal material
- Viton®
- Other characteristics
- spring, compact, standard
- DN
0.25 mm, 0.375 mm, 0.5 mm, 0.75 mm, 1 mm
(0.01 in, 0.015 in, 0.02 in, 0.03 in, 0.039 in)- Pressure
2,500 psi
- Temperature
Max.: 400 °C
(752 °F)Min.: -15 °C
(5 °F)
Description
Spring-loaded, compact, stainless steel check valve.
316 stainless steel
Spring-loaded 2 lb. or 10 lb. cracking pressures
MNPT x MNPT
Usable on metering pumps and injection line applications
Suitable for pressures up to 2,500 PSI and temperatures from -15° to +400°F
Viton® or PTFE o-ring standard (other materials available)
