Single screw extruder SKW-105compoundingfor HFFRmodular system
Add to favorites
Compare this product
Characteristics
- Number of screws
- single screw
- Applications
- compounding
- Treated material
- for HFFR
- Other characteristics
- modular system
- Output
35 kg/h
(77.1618 lb/h)Max.: 800 kg/h
(1,763.6981 lb/h)Min.: 5 kg/h
(11.0231 lb/h)- Screw diameter
35 mm
(1.4 in)Max.: 132 mm
(5.2 in)Min.: 16 mm
(0.6 in)- Screw length
1,330 mm
(52 in)Max.: 3,000 mm
(118 in)Min.: 840 mm
(33 in)- Maximum speed
500 rpm
(3,142 rad.min-1)Max.: 800 rpm
(5,027 rad.min-1)Min.: 100 rpm
(628 rad.min-1)- Torque
6 Nm
(4 ft.lb)Max.: 12 Nm
(9 ft.lb)Min.: 8 Nm
(6 ft.lb)- Temperature
200 °C
(392 °F)Max.: 400 °C
(752 °F)Min.: 0 °C
(32 °F)- Maximum pressure
8 bar
(116 psi)Max.: 15 bar
(217.6 psi)Min.: 5 bar
(72.5 psi)- Overall length
1,500 mm
(59 in)Max.: 5,540 mm
(218 in)Min.: 840 mm
(33 in)- Overall width
900 mm
(35 in)Max.: 1,000 mm
(39 in)Min.: 800 mm
(31 in)- Total height
1,500 mm
(59 in)Max.: 2,000 mm
(79 in)Min.: 1,000 mm
(39 in)- Weight
5,000 kg
(11,023 lb)Max.: 6,000 kg
(13,228 lb)Min.: 2,000 kg
(4,409 lb)- Power
19 kW
(25.83 hp)Max.: 480 kW
(652.62 hp)Min.: 5 kW
(6.8 hp)
Description
Due to environmental protection and safety requirements, halogen-free flame retardant materials (HFFR) are increasingly used in low-voltage cables and building wires. In order to obtain higher quality HFFR compound, it is necessary to ensure that the high loading of flame retardants can be uniformly dispersed in the polyolefin resin, while processing at the lowest possible melt temperature. A stable and high-precision feeding system also becomes the key to maintaining product purity and consistency.
