Manual impulse sealer HTMST 1400-DN30 NA LP / SZ=170horizontalsachetfor film
Add to favorites
Compare this product
Characteristics
- Operating mode
- manual
- Orientation
- horizontal
- Product applications
- sachet, for film
- Product applications
- for packaging, for sacks
- Weld length
1,400 mm
(55.12 in)
Description
Film Sealing device
Technical data
• Fuse : 16 A, slow-blow
• Connected Voltage : 400 V
• Film passage : 1000 mm
• Weight : 260 kg
• Sealing wire upper bar : Flat heating band 6 mm x 0,25 mm x 1400/1750 mm
• Sealing wire lower bar : Flat heating band 6 mm x 0,25 mm x 1400/1750 mm
• Impulse time : digital in 0.1s steps
• Cooling time : digital in 0.1s steps
• Emergency stop : yes
• Range of action : 153 mm
• Bar opening : 30 mm
• Degree of protection : IP 54
• Max. sealing output : 2 x 0,4 mm PE-Foil
• Sealing : Impulse-heated
• Security feature : Machine stops automatically in case of an item bigger than 4 mm between the sealing bars during the sealing process.
• Control : SPS
