Heat-of-compression compressed air dryer DW series
compacthigh-qualityexternally heated

heat-of-compression compressed air dryer
heat-of-compression compressed air dryer
Add to favorites
Compare this product


Characteristics

Technology
heat-of-compression
Other characteristics
compact, high-quality, externally heated
Capacity

Min.: 17.6 m³/min (621.54 ft³/min)

Max.: 194.2 m³/min (6,858.11 ft³/min)

Description

The compact heat-regenerated desiccant dryers of the DW series deliver reliable drying performance down to a pressure dew point of −40 °C whilst also featuring generous fill levels of innocuous aluminium oxide desiccant. Desiccant regeneration is performed with externally heated blower air using the highly efficient reverse flow process. This boosts operational reliability whilst cutting operating costs. DTP to −40 °C Flow rate 17.6 to 194.2 m³/min Optionally available with ECO CONTROL DW dew point control Your advantages Highly energy efficient: DW-series desiccant dryers take advantage of the efficient reverse flow regeneration process and are additionally equipped with high-quality heat insulation. Reverse flow process with safety buffer: DW dryers use activated aluminium oxide desiccant – a water-resistant material with extremely high mechanical stability. The generously dimensioned desiccant fill level constitutes an emergency operation reserve in extreme situations. Cost-effective transport: DW dryers feature significantly lower height compared to competitors' models, which allows for straightforward transportation of all DW models by truck (articulated lorry).
