Layer palletizer TRACKPALwith robot on a track motion systemfor bottle packsfor the food and beverage industry
Add to favorites
Compare this product
Characteristics
- Type
- layer, with robot on a track motion system
- Product applications
- for the food industry, for sacks, for boxes, industrial, for the food and beverage industry, plastic crates, for boxes, for bottle packs, for production lines, for chemicals, food, for industrial applications, for food
- Operating mode
- automatic, continuous, dual-line
- Robot type
- Cartesian
- Sector
- for the food industry, for bottling industry, for the chemical industry, for the pharmaceutical industry, construction
- Other characteristics
- high-speed
- Throughput
3 p/min
- Pallet width
Max.: 1,000,000 mm
(3,280.84 in)800 mm
(31.5 in)Min.: 600 mm
(23.62 in)- Pallet length
Max.: 1,400 mm
(55.12 in)1,200 mm
(47.24 in)Min.: 600 mm
(23.62 in)- Pallet weight
1,500 kg
(3,306.93 lb)- Maximum palletizing height
2,300 mm
(90.55 in)- Machine length
6,000 mm
(236.22 in)- Machine width
2,500 mm
(98.43 in)- Machine height
3,950 mm
(155.51 in)- Overall weight
175 kg
(386 lb)- Electric powered
400 V
- Payload
175 kg
(385.81 lb)
Description
The double-output palletizer on Track TRACKPAL is an innovative solution designed to create pallets with great stability, reaching heights of up to 2700 mm. This system equips a dual palletizing zone to avoid production stops during pallet changes, ensuring a continuous and efficient workflow.
It is ideal for industries handling big amount of boxes of various dimensions and weights. TRACKPAL offers a versatile solution adaptable to different needs. Its ability to generate palletizing patterns and its robust design make it an essential tool for improving productivity and optimizing palletization process.
It is perfect for the following sectors:
ADVANTAGES
Efficiency:
Low consumption, IEE (Intelligent Energy Efficiency).
The motorized elements remain at rest until they need to move product and, in turn, stop if they do not receive product after a certain period of time.
Features:
Simple and intuitive creation of mosaics by the operator using proprietary software.
Reversed layer function for improved stability.
Safety and ergonomics:
Study and treatment of safety and ergonomics from the start of the design process, machine subjected to risk analysis and auditable risk assessment.
Touchscreen interface with various levels of accessibility, allowing you to adjust all parameters that influence the machine's performance. (Recipes, Timers, Speeds, Counters, etc.)
Durability
Machine manufactured from steel processed using laser cutting, water jet cutting, bending, electro-welding, and precision parts made in machining centers.
Structures and thicknesses optimized using specialized software calculations.
Combined finishes in two-component polyurethane, epoxy paint, galvanized and/or stainless steel.
OPTIONS
It is ideal for industries handling big amount of boxes of various dimensions and weights. TRACKPAL offers a versatile solution adaptable to different needs. Its ability to generate palletizing patterns and its robust design make it an essential tool for improving productivity and optimizing palletization process.
It is perfect for the following sectors:
- Chemical
- Ceramic
- Fruit and vegetable
- Food and beverages
- Industry
- Pharmacist
ADVANTAGES
Efficiency:
Low consumption, IEE (Intelligent Energy Efficiency).
The motorized elements remain at rest until they need to move product and, in turn, stop if they do not receive product after a certain period of time.
Features:
Simple and intuitive creation of mosaics by the operator using proprietary software.
Reversed layer function for improved stability.
Safety and ergonomics:
Study and treatment of safety and ergonomics from the start of the design process, machine subjected to risk analysis and auditable risk assessment.
Touchscreen interface with various levels of accessibility, allowing you to adjust all parameters that influence the machine's performance. (Recipes, Timers, Speeds, Counters, etc.)
Durability
Machine manufactured from steel processed using laser cutting, water jet cutting, bending, electro-welding, and precision parts made in machining centers.
Structures and thicknesses optimized using specialized software calculations.
Combined finishes in two-component polyurethane, epoxy paint, galvanized and/or stainless steel.
OPTIONS
- Labeling machine integration.
- Automatic pallet dispenser and changer.
- Reversed layer function for improved stability.
- Add pallet between layers function. (Manual or automatic).
- KTS, remote assistance.
- Full stainless steel finishes
