Bevel gear reducer 4115.00
coaxial1 - 5 Nm5 - 10 Nm

bevel gear reducer
bevel gear reducer
Add to favorites
Compare this product

Characteristics

Type
bevel
Shaft orientation
coaxial
Torque
1 - 5 Nm, 5 - 10 Nm
Performance
high-speed
Other characteristics
linear, for lifting applications, for automotive applications

Description

Bevel gear with syncronous telescopicspindle 4115.00 Twofold telescopic lifting unit with bevel gear head for various linear drive solutions. Ideal for electromotive sit-stand workplace applications or wherever an infi nite linear adjustment is required at a high speed, maximum stroke with a minimum installation dimension. The lifting unit is available in customized spindle lengths. Special features - Double speed through synchronous telescope design - Maximum stroke with minimum installation dimension - With gear head 3039 or 3045 - Ratio 1:1 - Drive torque on gear head : max. 4 Nm or 5.5 Nm - Hardened steel bevel wheels with robust, reinforced toothing - Ideal for electromotive drives - Available in different spindle lengths Technical notes - The lifting units must be protected against lateral forces by a separate guide system. - Attention: The spindle systems with a spindle pitch > 3mm may not be self-locking. Check the self-locking effect in the application. - The lifting unit is only pressure loadable. - Incorrect dimensioning of the guide system can damage the lifting unit: Please note the design and safety instructions for spindle drives.
