Linear positioning table motorizedsingle-axis
Add to favorites
Compare this product
Characteristics
- Orientation
- linear
- Type
- motorized
- Number of axes
- single-axis
Description
No marking out before punching required.
Distance between holes is always correct, even when plates are not square or the batch of plates vary in size.
When plates fitted on site they always fit.
Due to 'user friendly' control it is ideal for large or small batches of plates.
Punching of plates, flat steel, in the web of channel and on the flange of channel and I-beams. The punching of the web in channel is effected with the flanges up and by using extended length punches. The table is delivered complete with servo-motor and 2 axis measuring system, and is equipped with an easy to operate Robosoft K210 (or optional M600) control.
VIDEO
