Piezoelectric generator 6906

laboratory

Product overview
The Kistler pressure generator Type 6906 is designed to calibrate and verify piezoelectric pressure sensors by producing continuous hydraulic pressure. Stable loading cycles (10 … 30 s) enable precise quasi-static calibrations up to 10000 bar.

Main features

• Hydraulic continuous pressure generator for piezoelectric pressure sensors
• Pressure range up to 10000 bar
• Suitable for quasi-static calibration and verification with 10 … 30 s loading cycles

Technical data
Product identifiers

• Model: 6906
• Article number / Code: 18006793

Mechanical properties

• Stroke per spindle revolution: 1.75 mm
• Piston stroke: 76 mm
• Pressure transmission medium: Kistler Type 1053 Oil

Metrological characteristics

• Range: 0 … 10000 bar

Influence quantities

• Approximate pressure loss: 0 bar/min

Dimensions and materials

• Piston diameter: 6 mm
• Swept volume: 2.14 cm3
• Oil reservoir: 22 cm3

Characteristics / technical specifications

• Type: Continuous hydraulic pressure generator for piezoelectric sensors
• Intended use: Quasi-static calibration / verification of piezoelectric pressure sensors
• Max. pressure: 10000 bar
