Time counter Codix 560

batchbinarytachometer

Preset counter – counter, tachometer, hour meters / timers and position display in one device. The large multi-function preset counter Codix 560 guides the user through the programming with automatic help texts on a large 14-segment LED display, making it easy to understand. Clear cursor keys simplify operation. The large front keys are easy to operate even when wearing gloves. The 14 mm high LED display makes it easy to read even from a distance and in poor lighting conditions. New: Now also available with RS232/485 interface with MODBUS and CR/LF protocol. Benefits Versatile functions Counter, tachometer, time counter and position display in one device As preset counter, batch counter or total counter 2 relays (changer) Many different counting modes Scalable display Set value, steps, or trailing presets Multi-range power supply for AC or DC Readable via RS232/485 interface or configurable via MODBUS or CR/LF protocol Direct connection of large display or printer possible Convenient operation Automatic help texts in German or English 14-segment LED for better text display Status display of the presets 3 predefined parameters Trailing presets save the need for reprogramming the presignal Low installation depth 4-stage RESET modes 3-stage keyboard lock Suitable for installation in mosaic systems
