Leakage testing system C870H

massperformancenetwork

Overview
The C870H integrated loss-on-drying testing system uses the gravimetric method and is designed to meet pharmacopeia and industry testing standards for pharmaceutical, food and chemical laboratories. It is intended for routine and high-throughput loss-on-drying and moisture determinations.

Product features
Precise, traceable and convenient measurement

• Independent dual-chamber design separates drying and weighing to prevent high-temperature effects on the balance.
• Automatic sample-weight determination to reduce operator influence.
• High-precision touchscreen electronic balance (German-imported) with repeatability to 0.05 mg.
• Visualized balance operation and traceable data export for audit trails.
• Internal calibration balance for quick removal and easy maintenance.

Safe and compliant

• Automatic test-cup cover opening/closing ensures consistent handling and regulatory compliance.
• Automatic temperature adjustment supports true room-temperature weighing.
• Fully enclosed, zero-leakage test chamber prevents hazardous gas escape.
• Nitrogen circulation and discrete electrical control systems provide dual safety protection.
• Built-in sensors with audible and visual alarms enhance operational safety.

Intelligent and efficient

• Fully automatic gripper handles up to 36 test cups for high-throughput operation.
• Bidirectional rotation control and adjustable number of rotating cups simplify filling and handling.
• Automatic liquid-cooling operations (fill/drain/level detection) reduce manual tasks.
• Drying, cooling and room-temperature weighing are fully automated without human intervention.
• 12.1" medical-grade touchscreen enables standalone operation without a PC.
• Desktop host design saves bench space and adapts to varied laboratory layouts.
• Embedded network port supports remote control and firmware upgrades.
• Professional software supports GMP traceability and multi-level user access; electronic signature aligns with 21 CFR Part 11 (optional).

Testing principle
Mix the sample thoroughly (crush large crystals to < 2 mm if required). Weigh approximately 1 g or the weight specified by the test standard and place the sample into a test cup dried to constant weight under the same conditions. Weigh accurately and, unless otherwise specified, dry at 105 °C to constant weight. Calculate loss-on-drying from the weight loss relative to the sample weight.

Reference standards

• USP, EP, BP, JP, ChP and other pharmacopeias.
• GB 5009.3-2016 and other food testing standards.
• GB/T 6284, JIS K 0068 and other chemical-testing standards.

Applications

Basic applications - Pharmaceuticals: loss-on-drying and moisture content determination for pharmaceutical materials and products.

Extensive applications - Food: moisture and loss-on-drying analysis for food and feed products.
- Chemicals: loss-on-drying testing for various chemical products and raw materials.

Technical parameters (summary)

• Model: C870H
• Test range (mg): 0.05 ~ 20000; optional 0.3 ~ 40000
• Resolution (mg): 0.01; optional 0.1
• Repeatability (mg): ±0.05; optional ±0.3
• Temperature range (°C): Room temperature ~ 130; fluctuation ±0.5 °C
• Test pressure (kPa): 0 ~ −20 (customizable)
• Test stations: 36
• Test cup volume: 40 mL (customizable)
• Gas: compressed air (user-supplied); gas source pressure 0.5–0.7 MPa
• Host dimensions: 83 cm × 110 cm × 73 cm
• Power supply: 120 VAC ±10% 60 Hz or 220 VAC ±10% 50 Hz
• Net weight: 200 kg
• Standard configuration: host, balance (0.01 mg), liquid-cooling module, gas-drying module, 36 test cups, Φ8 mm polyurethane tube
• Optional: GMP computer system, 21 CFR Part 11, compressors, alternative balances and test-cup volumes

Notes
All described features depend on the selected technical parameters. Performance data were obtained under Labthink laboratory conditions by professional operators. Test pressure and cup volume can be customized; test range may vary with configuration.
