CNC router MCNC CF20
3-axisspindlefor composites

CNC router
CNC router
Add to favorites
Compare this product

Characteristics

Control type
CNC
Number of axes
3-axis
Number of spindles
spindle
Treated material
for composites
Other characteristics
vacuum

Description

SmartShop® Composite Fabricator 20 The SmartShop Composite Fabricator is specifically designed for cutting Aluminum Composite Panel (ACP) or Aluminum Composite Material (ACM). ACM is a widely used term describing flat panels that consist of a non-aluminum core bond between two aluminum sheets. Aluminum sheets can be coated with PVDF or polyester paint. ACPs are frequently used for external cladding of buildings (building facades), for insulation and for signage. Laguna has fabricated the perfect machine to conquer this material. Features: •Huge machining area 6’ x 20′ —2000mm x 6000mm *Custom sizes available. •Unique Pressure “Shoe” design for optimum depth accuracy- even if the panel is not completely flat. •Helical Rack and Pinon drives on X and Y axes. Ball screw on Z axes. •1,2 and 3 spindle design. Also available with ATC spindle. •(3) 6HP Italian HSD spindles shown on the machine below.
