Cellular single chip modem Pinnacle™ 100

BluetoothNB-IoTlow-power

The Pinnacle 100 is an End Device Certified cellular socket modem that combines low-power cellular with Bluetooth 5 technology into a fully integrated hardware platform. It seamlessly incorporates a powerful Cortex M4F controller, full Bluetooth 5 connectivity, and dual-mode LTE-M/NB-IoT capabilities – all with full regulatory, network certifications, and End Device (socket modem) carrier approvals. Develop your BLE-to-Cloud Applications using Python! Our Canvas™ software suite enables rapid embedded development across our MCU-based wireless products. Build your wireless IoT application in days, not months, with embedded Python scripts. Start with our feature-rich sample apps and customize to create your next big thing. Learn more at ezurio.com/canvas. Application Development Environment VS Code development environment to develop Python applications for Canvas hardware Sample Python scripts for BLE, MQTT, HTTP, and LWM2M connectivity Advanced deployment tools including mobile app (Android and iOS) to update device firmware, as well as engineering services support. Cellular & Bluetooth with co-located radio testing LTE-M/NB-IoT capabilities via Sierra Wireless HL7800 module MCU / Bluetooth 5 radio via Nordic nRF52840 – Bluetooth 5, Coded PHY (LE Long Range), 2MPHY, Bluetooth Mesh - Cortex-M4F – 32-bit @ 64 MHz, 256 KB of RAM, 1 MB internal flash, 8 MB QSPI Multiple Antenna Options – The only cellular solution to have low-cost pre-integrated internal and multiple external antenna options with u.FL connectors Globally & Carrier Certified – Speed your designs to market by leveraging FCC, ISED, EU, UKCA, Bluetooth SIG, PTCRB, GCF, AT&T, and Verizon certifications.
