Cut-off saw max. ø 400 mm | Delta Swing Digit

for aluminumsemi-automatic

Machine equipped with electronic positioner c/w monochrome screen 120x40 mm and industrial integrated keyboard USB port to store/upload of cutting lists and programs Right head displacement by means of electronic postioner Sliding of the moving head by means of ricirculating ball bearings on rectified and tempered guides Full protection of the sawblades by means of safety hoods with automatic closing Pneumatic heads tilting at 90° a + 45° - 45° Possibility to perform intermediate degrees by means of a mechanical end stop Max. cutting capacity 4000/5000 mm Max.sawblade Ø 400mm Sawblade shaft Ø 30mm 1,5 Kw (2 HP) 3 phase motors - 2800 r.p.m. Working pressure 7 bar Overall dimensions 501x125x136 cm Weight 750 Kg
