Beverage carbonation mixing unit

Product overview
The VM-Series vacuum mixing tank is designed for industrial-scale mixing, emulsifying and optional vacuum degassing of liquid and viscous products. Constructed from high-grade stainless steel with mirror polishing, the unit integrates top and bottom agitators, an electric control panel and a modular platform for safe operation.

Applications
Used as a blending tank, mixing tank, preparation tank, fermentation tank or disinfection tank. Suitable for industries such as food and beverage, dairy, pharmaceuticals, cosmetics, chemical and biological engineering.

Key features

• Stainless steel tank body with mirror finish for hygienic processing.
• Top and bottom motors for efficient mixing and homogenization.
• Heating options: steam jacket, electric heating element, or non-heated version.
• Easy discharge: bottom direct outlet or pump discharge.
• Optional vacuum degassing system available to remove entrapped air.
• Customizable capacity from 50 L to 5000 L.

Technical specifications

• Material: high-quality stainless steel, mirror polished.
• Main components: main tank, upper motor, bottom motor, electric control panel, operation platform.
• Heating options: steam heating, electric heating, or no heating (jacketed or non-jacketed).
• Discharge method: bottom direct discharge or pump discharge.
• Capacity range: 50 L to 5000 L (customizable).
• Functions: blending, mixing, preparation, fermentation, disinfection; optional vacuum degassing.
• Applicable industries: food, dairy, beverages (fruit juice), pharmaceutical, chemical, biological engineering.
• Typical products: liquid soap, laundry detergent, shampoo, hand wash, hair gel, body wash.
