LED floodlight MLLG-LED-SBHO2-150-50B

IK 08IP65energy efficiency

Product Overview
This 150W LED billboard light MLLG-LED-SBHO2-150-50B delivers 24,000 lumens for billboard, sign and outdoor advertising illumination. Available in 4000K or 5000K color temperatures and compatible with 100V-277V or 277V-480V input voltage options.

Core Performance and Output
Produces 160 lm/W with a 70+ CRI and is specified as a replacement for 400W metal halide fixtures. Standard Type 5 distribution provides broad, even coverage across sign faces; Type 3 optics are available as an option. Supports 1-10V dimming. Driver operates at 50-60Hz with power factor > 0.92 and THD < 15%.

Key Features

• Brand: LED Lighting Supply
• Model / SKU: MLLG-LED-SBHO2-150-50B
• Wattage: 150 W
• Lumen output: 24,000 lm
• Efficiency: 160 lm/W
• Replaces: 400 W metal halide
• Input Voltage: 100V-277V or 277V-480V
• Color Temperature: 4000K or 5000K
• CRI: 70+
• Dimming: 1-10V
• Distribution: Type 5 (Type 3 optional)
• Optics: Polycarbonate lens
• L70 Lifespan: 244,000 hours
• Mounting: Yoke or Slip Fitter
• EPA Rating: 0.43 (ARM mount)
• Fixture Color: Bronze
• Frequency: 50-60 Hz
• Power Factor: > 0.92
• THD: < 15%

Durable Construction
Die-cast aluminum housing with IP65 and IK08 ratings. Built-in surge protection (6kV line-line, 10kV line-earth). Operating temperature range -22°F to 113°F (-30°C to 45°C). ETL and DLC Premium certified. 5-year warranty.

Measurements
Dimensions: 15.63 L x 11.25 W x 3.22 H in. Weight: 9.48 lbs.

Features / Accessories

• Photocell (optional)

Where This Product Fits Best

• Billboard lighting
• Sign lighting
• Outdoor advertising lighting
• Monument sign lighting
• Building signage lighting
• Roadside sign lighting
• Pylon sign lighting

Safety, Certifications and Warranty
ETL and DLC Premium certified. 5-year warranty.

Technical specifications

• Brand: LED Lighting Supply
• Model / SKU: MLLG-LED-SBHO2-150-50B
• Wattage: 150 W
• Lumen output: 24,000 lm
• Efficiency: 160 lm/W
• Replaces: 400 W metal halide
• Input Voltage: 100V-277V or 277V-480V
• Color Temperature: 4000K or 5000K
• CRI: 70+
• Dimming: 1-10V
• Standard Distribution: Type 5 (Type 3 optional)
• Optics / Lens: Polycarbonate lens
• L70 Lifespan: 244,000 hours
• Mounting Options: Yoke or Slip Fitter
• EPA Rating: 0.43 (ARM mount)
• Fixture Color: Bronze
• Frequency: 50-60 Hz
• Power Factor: > 0.92
• THD: < 15%
• Housing: Die-cast aluminum
• IP Rating: IP65
• IK Rating: IK08
• Surge Protection: 6kV line-line, 10kV line-earth
• Operating Temperature Range: -22°F to 113°F (-30°C to 45°C)
• Certifications: ETL, DLC Premium
• Warranty: 5 years
• Dimensions: 15.63 x 11.25 x 3.22 in
• Weight: 9.48 lbs
• Accessories: Photocell (optional)
