Modular building

temporarydisassemblabletransportable

Overview
Insulated temporary modular buildings designed to control interior temperature, improve thermal comfort for staff and reduce energy consumption for heating or cooling. The roof assembly provides approximately six times the insulation of standard double-roof systems while remaining quick to install.

Key benefits

• Eco-designed: minimal raw material use and integration of recycled materials in the insulating component.
• Temperature control: thermal performance significantly superior to common double-roof or overpressed roof systems.
• Energy savings: lower heating/cooling consumption compared with non-insulated double-roof solutions.
• Rapid delivery and assembly: insulated modular units can be delivered turnkey in less than 20 days.
• Flexible installation: can be installed on compacted ground without foundations, positioned individually, attached to existing buildings or linked together while remaining demountable and transferable.

Applications
Suitable for multiple industrial and commercial uses: temporary retail or public reception during construction works, protection and storage of temperature-sensitive goods, temporary workshops or long-term facilities where reduced energy use and transferability are required.

Additional features

• Installation possible on compacted ground without permanent foundations (base plates fixed by piles or concrete anchors).
• Compatibility with a wide range of accessories: lighting options, wall and post protections, rainwater collection systems and multiple access/handling solutions.

Technical specifications

• Span: from 10 to 30 m.
• Length: in multiples of 5 m.
• Side height: 3 to 6 m.
• Ridge height: 3.50 to 12 m.
• Ground anchoring: base plates fixed by piles or concrete anchors.
• Frame: aluminium profile.
• Roof: patented system combining two flexible PVC composite membranes on a white translucent polyester support (650 g/m² and 490 g/m²) treated anti-UV and anti-dust, coated both sides, with a 75 mm insulating layer based on recycled PET fibres (thermal and acoustic performance). Tension bars on roof edges.
• Lighting: LED, chandelier, fluorescent, emergency lighting (depending on use and regulation).
• Perimeter walls: double-roof with insulating component; insulating sandwich wall panels available.
• Main access: pedestrian doors or panic doors (single or double leaf), automatic glazed doors. For handling and trucks: lifting canvas panel, sliding fabric curtain, double-leaf sliding gate.
