Polyurethane adhesive tape DuploTEC® SBF

permanentfilmfor composite materials

Overview
Combine the benefits of pressure-sensitive adhesive tapes and liquid adhesives to deliver improved cost-efficiency, increased process reliability and higher bonding strength. Structural bonding films and tapes are designed for semi-structural and structural bonding applications and enable quick, clean processing thanks to dimensional precision and pre-applicability.

Innovative Reactive Films and Tapes

• Reactive films and tapes provide dimensional precision and are pre-applicable for fast, clean processing.
• Available chemistries include thermosetting polyurethane and thermosetting epoxy.
• UV-activatable tape technology (UV-LUX®) offers semi-structural properties via a cross-linking mechanism.

UV-LUX® — UV-Activatable Tape
UV-LUX® is a UV-light activatable adhesive tape solution with a color change on activation. It enables dark curing (no continuous thermal input required) and provides initial tack for easy placement plus a visible color change to control activation. Typical behavior supports quick manufacturing processes and reliable handling immediately after activation.

UV-LUX® — Key process & performance points

• UV-activation with ~365 nm in seconds.
• Color change at activation (optional) for process control.
• Up to ~10 minutes open time (processing window) depending on application.
• Immediate handling strength after activation; full strength typically reached after ~24 hours.
• Enables curing in dark after UV activation; reduces need for heat or translucent materials.

DuploTEC® SBF — Polyurethane High-performance Bonding System
Strong, flexible and quick to process. Rapid network formation at low temperatures makes this adhesive film suitable for short cycle times and processes requiring maintained flexibility after curing.

Polyurethane — Technology & process

• Thermosetting polyurethane adhesive system (solvent-free, dry adhesive film).
• Latent reactive formulation with structural bonding characteristics.
• Pre-applicable between approx. 50–55 °C; allows storage up to about 3 months after pre-application.
• Activation typically between ~70–160 °C; activation within seconds possible depending on formulation.
• Low curing temperatures; remains elastic and flexible after curing.
• Individual and precise adhesive dimensions available.

DuploTEC® SBF — Epoxy Adhesive Systems and Tapes
Combines pressure-sensitive tape-like initial tack with structural bonding performance after curing. Suitable where high heat and chemical resistance as well as high strength are required.

Epoxy — Technology & process

• Epoxy-based thermosetting tape with initial adhesion (PSA-like application).
• Structural bonding performance after curing; highly resistant to ageing and chemicals.
• Curing starts from ~130 °C (266 °F); curing time depends on temperature and formulation.
• Adaptable to individual process conditions; minimum pressure for application approx. 1 N/cm².

Your benefits

• PSA-like applicability with initial tack for easy placement.
• Safe and controlled process through color change and measurable open time (UV-LUX®).
• Semi- and full-structural bonding behaviors available depending on chemistry.
• Fast activation (UV in seconds) and processing windows; immediate handling strength for downstream processes.
• High temperature and chemical resistance (epoxy variants); elastic, flexible bonds (polyurethane variants).

Applications & positioning
The SBF range combines structural bonding performance with the ease of use of adhesive tapes. It targets industrial bonding tasks where conventional pressure-sensitive adhesives need enhanced strength or where process reliability and short cycle times are essential.

Technical characteristics / specifications

• Product family: DuploTEC® SBF (Structural Bonding Films and Tapes)
• Chemistries: Epoxy and Polyurethane; UV-activatable variant (UV-LUX®) available
• Form factors: Pre-applicable dry adhesive films and tapes with initial tack
• Polyurethane pre-application: ~50–55 °C; storage up to ~3 months after pre-application
• Polyurethane activation: ~70–160 °C; activation within seconds possible
• Epoxy curing start: from ~130 °C; cure time dependent on temperature and formulation
• UV activation: ~365 nm; color change on activation (optional)
• Processing: Immediate handling strength after activation; full strength typically ~24 hours
• Application pressure: min. ~1 N/cm² recommended for epoxy systems
• Properties: Semi-structural to structural bond strength; ageing and chemical resistance (epoxy); elasticity and flexibility after cure (polyurethane)
