Progressing cavity pump unit B70V-D

for food productswith electric motorself-priming

Description
The eccentric screw pump unit B70V-D in PURE design is a positive-displacement pump for medium to high viscosity and highly viscous media up to the limits of flowability. Depending on the application, different three-phase motors are available and can be combined with the pump unit at any time to ensure operational flexibility and resource efficiency.

• also available in special immersion depths
• example media: viscous cosmetic products, food products, etc.

Features & Benefits

• Consistent volumetric flow
• Easy and fast cleaning
• Gentle, low-pulsation product transfer
• Quiet operation and low wear
• Wide range of robust, high-performance drive motors
• Approved according to ATEX Directive 2014/34/EU, Category 1/2

Technical data
Connection: Tri‑Clamp
Drive shaft (material): Stainless steel (1.4571)
Seal type: Mechanical seal (GLRD)
Discharge nozzle (DN): 50
Explosion protection: No
Max. discharge pressure (bar)*: 6
Max. conveyed medium temperature (°C): 140
Max. flow rate (l/min)*: 12
Drive / impeller type: Torsion shaft (for medium-viscosity media)
Mechanical seal (materials): WC, SiC, EPDM
Pump housing material: Stainless steel (1.4571 / 1.4404)
Rotor (material): Stainless steel (1.4571)
Static seal (material): EPDM
Stator (material): PTFE (polytetrafluoroethylene)
Stator size: 12.1
Max. immersion tube diameter (mm): 54
Immersion depth (mm): 1000
Type: B70V-D PURE
Max. viscosity (mPas)*: 100000
Certification: FDA-compliant, Regulation (EC) 1935/2004

Characteristics / Technical specifications

• Connection: Tri‑Clamp
• Drive shaft: Stainless steel (1.4571)
• Seal type: Mechanical seal (GLRD) – materials WC, SiC, EPDM
• Discharge nozzle: DN 50
• Explosion protection: No
• Max. discharge pressure: 6 bar
• Max. conveyed medium temperature: 140 °C
• Max. flow rate: 12 l/min (test bench value, see notes)
• Drive type / impeller form: Torsion shaft (for medium-viscosity media), cardan shaft optional
• Pump casing and rotor materials: Stainless steel (1.4571 / 1.4404)
• Stator: PTFE, stator size 12.1
• Static seal: EPDM
• Max. immersion tube diameter: 54 mm, immersion depth: 1000 mm (special immersion depths available)
• Type designation: B70V-D PURE
• Max. viscosity: up to 100000 mPas
• Certifications: FDA-compliant, Regulation (EC) 1935/2004
