Desiccant compressed air dryer DRC series

in-linethermal mass

Overview
MAC3 supplies the DRC series thermal mass dryers with integrated line filters. These dryers are designed for industrial compressed air systems and combine compact construction with corrosion-resistant stainless steel components.

DBP externally regenerated adsorption dryers

• Dew point: 3°C
• Integrated line filters: ≤ DRC 3330 (MX): Filtration 1 µm; (MY): Residual oil 0.01 µm
• Refrigerant: R-513a
• Max. operating pressure: 15 bar
• Max. ambient temperature: 50°C
• Max. input temperature: 60°C
• Controllers: DIGIPRO (495–930) or ESD controller (≥ DRC 1200)
• Stainless steel components

Energy / cooling system
Dryers adapt their energy consumption to the airflow. The cooling system lowers the temperature of the water–glycol mixture by up to 1°C and stores it in a stainless steel tank. A small pump circulates the mixture to cool the compressed air. The cooling compressor stops when the mixture reaches the set temperature, providing energy savings.

Fields of application

• Woodworking
• Power generation
• Food industry
• Metallurgy
• Major industries
• Crafts
• Agriculture
• Medical – Pharmaceutical
• Surface treatment
• Automotive industry

Performance (selected models)
Model | Power supply | Flow m3/min | Connection | Integrated filters | Dimensions (LxWxH) mm | Weight Kg
DRC 495 | 230/1/50 | 8.25 | G 2" | HGKON805 MX+MY | 855 x 725 x 1505 | 178
DRC 623 | 230/1/50 | 10.4 | G 2" | HGKON805 MX+MY | 855 x 725 x 1505 | 184
DRC 930 | 230/1/50 | 15.5 | G 2" | HGKON1205 MX+MY | 830 x 730 x 1765 | 242
DRC 1200 | 400/3/50 | 20.0 | G 2" | HGKON1205 MX+MY | 830 x 730 x 1765 | 253
DRC 1388 | 400/3/50 | 23.1 | G 3" | HGKON-HC-1805 MX+MY | 1150 x 800 x 1740 | 295
DRC 1800 | 400/3/50 | 30.0 | G 3" | HGKON-HC-1805 MX+MY | 1150 x 800 x 1740 | 310
DRC 2500 | 400/3/50 | 41.7 | G 3" | HGKON-HC-1805 MX+MY | 1315 x 880 x 1790 | 411
DRC 2775 | 400/3/50 | 46.3 | G 3" | HGKON-HC-2275 MX+MY | 1315 x 880 x 1790 | 443
DRC 3330 | 400/3/50 | 55.5 | DN100 | HGKON-HC-2275 MX+MY | 1400 x 850 x 1840 | 537
DRC 3915 | 400/3/50 | 65.3 | DN100 | - | 1400 x 850 x 1840 | 557

Technical specifications

• Series: DRC (examples: DRC 495, 623, 930, 1200, 1388, 1800, 2500, 2775, 3330, 3915)
• Dew point: 3°C
• Integrated line filtration options up to residual oil 0.01 µm on specified versions
• Refrigerant: R-513a
• Maximum operating pressure: 15 bar
• Maximum ambient temperature: 50°C
• Maximum inlet temperature: 60°C
• Controllers: DIGIPRO for smaller units (495–930); ESD controller for units ≥ DRC 1200
• Construction includes stainless steel components
