AC/DC power supply MODEL 5211
regulatedstabilizedvariable-output

Add to favorites

Compare this product

Go to the MAGTROL website for more information

Characteristics

Type

AC/DC

Output

regulated, stabilized, variable-output

Protection

with short-circuit protection, with overcurrent protection

Mounting

tabletop

Features

case

Secondary function

measuring device

Applications

laboratory, for industrial applications, electronic equipment, for clutch and brake controls

Other characteristics

portable, benchtop, high-performance, analog, stand-alone, portable

Input voltage

120 V, 240 V

Output voltage

24 V

Current

Min.: 0 mA

Max.: 1,000 mA

Description

The 5211 is a 0-1A current-regulated 24 VDC power supply and display that is designed for use with Magtrol’s hysteresis brakes and clutches. It features a 10-turn current adjustment potentiometer and 3 selectable current ranges: 200 mA, 500 mA, and 1000 mA. A convenient built in panel meter displays the value of output current. The 5211 is designed as a closed-loop power supply to provide smooth application of current throughout an entire range up to a maximum set point. By utilizing regulated current, fluctuations in brake torque caused by temperature changes within the brake coil are eliminated. Braking current can be controlled manually from the front panel using the 10-turn potentiometer. Alternatively, if remote operation is required, the 5211 can be controlled by an external source using the 0-5 VDC control input located on the rear panel.
