Carbon fiber prepreg 316 series

epoxy resin

316 is suited for use where fire retardant materials are either preferable or mandatory such as electronic and measurement devices as well as electrical enclosures. While the key feature of this material is its conformance to UL 94 V-0 requirements, this system is favored for its versatile processing, excellent mechanical properties and cost efficiency. 316 can be supplied with most commercially available fibers (carbon, quartz, aramid, S-glass, E-glass, etc.) in both woven form (designated as NB) as well as unidirectional tape (designated as NCT). Woven fabrics are available in standard commercial widths up to 60 inches (1.5m). Unitape widths up to 39 inches (1m) are available in standard fiber weights ranging from 70-300gsm (0.014-0.060psf). Recommended processing conditions 316 can be cured at temperatures from 250-300°F (121-149°C), depending on part size and complexity. Low, medium, and high pressure molding techniques may be used for curing. Recommended cure cycle is 45 psi (310 kPa), 3°F (1.7°C)/min. ramp to 275°F (135°C), hold for 60 minutes, cool to <140°F (60°C).
