Accumulation conveyor
beltslattable top chain

Accumulation conveyor - MODU System (M) Sdn.Bhd. (MODU Group) - belt / slat / table top chain
Accumulation conveyor - MODU System (M) Sdn.Bhd. (MODU Group) - belt / slat / table top chain
Accumulation conveyor - MODU System (M) Sdn.Bhd. (MODU Group) - belt / slat / table top chain - image - 2
Add to favorites
Compare this product
Go to the MODU System (M) Sdn.Bhd. (MODU Group) website for more information

Characteristics

Technology
belt, slat, table top chain, slat chain
Form
horizontal, with adjustable slope, curved, vertical, straight, Z type, linear, U type
Function
transporting, for materials handling, loading, accumulation, storage, distribution, alignment
Construction
modular, flexible, height-adjustable, wide
Drive mechanism
electric drive, automatic, chain drive
Transported product
for boxes, food, for bulk materials, for pallet, bag, for packaging, for cans, parts, chip, cans, for bottle packs, for plastic pellets, package, for bottles
Applications
for medium loads, for small loads, for process applications, for clean rooms, for industrial bakeries
Sector
for the food industry, for the pharmaceutical industry, for assembly, for the cosmetics industry, for the plastics industry, for the e-commerce industry, for the parcel industry, for the airport industry
Options and accessories
with storage area
Other characteristics
custom-made, continuous, sanitary
Maximum load

Max.: 100 kg
(220.462 lb)

Speed

Max.: 40 m/min

Effective width

Max.: 70 mm
(3 in)

Min.: 15 mm
(1 in)

Length

Max.: 20 m
(65'07" )

Chain pitch

25.4 mm
(1 in)

Weight

Max.: 7.5 kg
(16.53 lb)

Working temperature

Max.: 60 °C
(140 °F)

Min.: -10 °C
(14 °F)

Description

The S-Accumulation Conveyor is an in-line accumulation conveyor designed for first-in-first-out (FIFO) product accumulation, buffering and controlled product flow between production line operations. Its S-shaped conveyor layout provides efficient accumulation while maintaining product orientation and a consistent product flow.

The conveyor system helps balance production processes by providing temporary product buffering between different machines, workstations and processing stages. Its sanitary and easy-to-clean design makes it suitable for applications requiring high hygiene standards, including pharmaceutical, food, beverage and other clean production environments.

The S-Accumulation Conveyor is suitable for product accumulation, product buffering, FIFO conveying, production line buffering, material handling and automated conveyor systems.
