Concrete block making machine MVS-3012

automatic

MVS 3012 Block and Interlock Paverstone Machine is a specific design machine for block, interlock production which works fully automatic. The machine is programmed by PLC computer. All kinds of blocks, curbstones, paverstones can be produced by changing moulds. 20cm block can be produced 12, interlock paverstones can be produced 30 units in one press. Moulds are changing easly and take short time period by our new innovation mould changing system . Vibration on mould is expanded uniformly, because of using pneumatics bellow mould connections, Easy maintenance and service Machine Weight - 17000Kg Hydraulic Pump Power - Full Automatic - 22kw60lt + 4kw19lt + 11kw + 59lt/min Semi Automatic - 22kw60lt + 4kw19lt/mi Manual - 11kW 59lt/min Hydraulic Oil Capacity - 800lt Machine Mortar Bunker Capacity - 2x1750dm³ Machine Dimensions - 2900x7000x2700 mm Upper Vibration Power - 2×1.1kW Lower Vibration Power - 4×5.5kW Total MachinePower Usage - Full Automatic - 61,2kW Semi Automatic - 48,2kW Manual - 35,2kW Minimum Product Height - 50mm Maximum Product Height - 300mm Vibration Press Power - 52kN Press Capacity - 6000kg-100bar The Number of Product on a Pallette - 30 pcs interlock, 12 pcs block 200x400x200mm Wooden Pallet Dimensions - 1400x1000x40mm
