Concrete block making machine MVS-4218

automatic

MVS 4218 Block and Paverstone Machine is a specific design machine for block, interlock production which works fully automatic. The machine is programmed by PLC computer. All kinds of blocks, curbstones, paverstones can be produced by changing moulds. 20cm block can be produced 18, interlock paverstones can be produced 42 units in one press. Moulds are changing easly and take short time period by our new innovation mould changing system Due to using special design vibrators, productions are being smooth and quickly Vibration on mould is expanded uniformly, because of using pneumatics bellow mould connections, Easy maintenance and service. Machine Weight - 22000Kg Hydraulic Pump Power - Full Automatic - 30kw120lt + 22kw 60lt + 4kw19lt/min Semi Automatic - 30kw120lt + 4kw19lt/dk Manual - 30kw59 lt/min Hydraulic Oil Capacity - 1200lt Machine Mortar Bunker Capacity - 2x2000dm³ Machine Dimensions - 2900x8600x2700mm Upper Vibration Power - 4×0,72kW Lower Vibration Power - 6×5.5kW Total MachinePower Usage - Full Automatic - 91.8kW Semi Automatic - 69.8kW Manual - 65.8kW Minimum Product Height - 60mm Maximum Product Height - 300mm Vibration Press Power - 80kN Press Capacity - 7500kg-100bar The Number of Product on a Pallette - 42 pcs interlock, 18 pcs block 200x400x200mm Wooden Pallet Dimensions - 1400x1350x45mm
