Probe head-mounted temperature transmitter SENS100-39P-DW

wirelessexplosion-proofwaterproof

● Pipeline pressure testing has been widely used in major oil and gas fields and other industrial pressure testing areas. ● Explosion-proof design: flameproof aluminum shell, intrinsically safe circuit board system. ● Protection grade: IP67, fully sealed and waterproof design. ● Zigbee communication, which can be configured and tested by a coordinator or router in the network. ● 4-digit LCD display: pressure data, battery voltage. ● LED indication: reset indication, configuration mode indication, network access indication, data collection indication. ● Adjustable installation direction: access to on-site pipeline valve through live connection or adapter, the direction can be adjusted. ● Working environment: temperature, -40℃≤Tamb≤+65℃; atmospheric pressure: 80KPa～110kPa; humidity, 5%RH～95%RH ● Power supply: 3.6V battery power supply ● Accuracy class: 0.5 ● Measuring principle: piezoresistive ● Output signal: ZigBee ● Protection level: IP67 ● Case material: cast aluminum ● Contact medium material: 316LSS ● Process connection: 1/2″NPT(M) ● Range: 0～ 2.5 Mpa ● Weight: 1kg ● External dimensions of pressure transmitter: height 210×width 116×depth 137 Explosion-proof certification parameters ● Explosion-proof certificate number: CE13.2134X ● Explosion-proof mark: Ex ib ⅡC T4 Gb ● Rated voltage: 3.6V±1% Rated current: 50mA Rated power: 0.18W
