3-axis CNC milling machine YJ-CNC850vertical
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- vertical
- X travel
850 mm
(33 in)- Y travel
450 mm
(18 in)- Z travel
450 mm
(18 in)- Rotational speed
5,000 rpm
(31,416 rad.min-1)- Power
5 ch
(5 hp)- Work feed X-axis
Min.: 0 mm/min
(0 in/s)Max.: 750 mm/min
(0 in/s)- Work feed Y-axis
Min.: 0 mm/min
(0 in/s)Max.: 750 mm/min
(0 in/s)- Weight
2,100 kg
(4,629.71 lb)- Overall length
2,170 mm
(85.4 in)- Overall width
1,975 mm
(77.8 in)- Overall height
2,474 mm
(97.4 in)
Description
Table size 1270 x 305 mm
Table T slot (number x width) 3 X 1 6 mm
Guell travels 140 millimeters
Spindle nose to the table surface 85 ~ 585 mm
Head rotation (R & L) 45 °
Spindle taper NSP # 40
Feed rate 0.035 ~ 0.07 ~ 0.14
Spindle to the surface 510 mm
XY rapid movement 7.5 M / min
