Automatic transfer switch NPATS series

rack-mountdata centerremotely operated

Product overview
The RackPower NPATS rack-mounted Automatic Transfer Switch (ATS) provides automatic power redundancy for single-corded IT equipment in server racks and network cabinets. It enables seamless failover between primary and secondary power sources and supports remote switching and monitoring to maximize uptime and simplify capacity planning.

Key features

• Automatic, seamless transfer to secondary power when primary input fails (10 ms transfer time)
• Provides power redundancy for single-corded IT devices to reduce downtime
• Local switching on the ATS or remote switching via IP
• Remote monitoring of power metrics and outlet-level on/off via network
• Field-replaceable 2.00 in (51 mm) color LCD local meter
• Included circuit monitoring and outlet switching across all units
• Hydraulic-magnetic MCB overload protection

Standards and compliance

• CE / EMC certified
• LVD certified
• ISO 9001 / ISO 14001 certified
• RoHS3 and REACH compliant

Available models (selected SKUs)

• NPATS11003 | 39398 — 2U | 110V | 20A | 16 outlets (example: 10 NEMA) | NEMA L5-20P | 10 ft
• NPATS20803 | 39403 — 2U | 208V | 30A | 1 outlet (1 L630R) | NEMA L6-30P | 10 ft
• NPATS20804 | 39404 — 2U | 208V | 30A | 18 outlets (16×C13, 2×C19) | NEMA L6-30P | 10 ft
• NPATS11001 | 39396 — 1U | 110V | 15A | 10 outlets (10 NEMA) | NEMA L5-15P | 10 ft
• NPATS11002 | 39397 — 1U | 110V | 20A | 10 outlets (10 NEMA) | NEMA L5-20P | 10 ft
• NPATS20802 | 39402 — 1U | 208V | 20A | 9 outlets (8×C13, 1×C19) | NEMA L6-20P | 10 ft
• NPATS20801 | 39401 — 1U | 208V | 20A | 12 outlets (12×C13) | NEMA L6-20P | 10 ft

Technical specifications

• Function: Rack-mounted Automatic Transfer Switch (ATS) for single-corded IT devices
• Material: Mild steel with powder-coated finish (Jet Black, RAL 9005)
• Nominal voltage: 110V or 208V
• Frequency: 50–60 Hz
• Electrical load ratings: 15A, 20A or 30A by model
• Socket configurations: NEMA and IEC (C13/C19) combinations depending on SKU
• Plug types: NEMA L5-15P, L5-20P, L6-20P, L6-30P
• Cable length: 10 ft (≈3 m)
• Rack space: 1U or 2U depending on SKU
• Overload protection: Hydraulic-magnetic miniature circuit breaker (MCB)
• Transfer time: ~10 ms
• Operating temperature: -5 to 60 °C (23 to 140 °F)
• Operating humidity: 0–95% non-condensing
• Local meter: Field-replaceable 2.00 in (51 mm) color LCD
• Remote management: IP-based outlet switching and power monitoring; free management software provided

Applications

• Server racks, colocation, edge data centers, telecom closets and network cabinets requiring redundant power for single-corded equipment

Ordering and support

• Refer to SKU for configuration and socket layout. Contact your RackPower distributor or sales representative for ordering, firmware and integration support.
