Dummy module DT-5800

Product Details Terminal module, required module. The end card-mandatory module is used to stabilize internal bus communication, and display the diagnostic information of network adapter and general diagnostic. The DT-5800 must be involved in configuration, and will occupy one slot. If there is no DT-5800, it is unable to create configuration. Technical Parameters General Parameter Current Consumption: 26mA@5VDC Installation: 35mm DIN-Rail Dimension: 119*14*80mm Configuration: Configuration required, occupying one slot Diagnosis: Support module online state diagnostics, network adapter operation status diagnostics Environment parameters Horizontal Installation Operating Temperature: -35℃~60℃ Vertical Installation Operating Temperature: -35℃~50℃ Storage Temperature: -40℃~85℃ Environment Humidity: 5%~95%RH (No condensation) Installation Altitude: <2000m Pollution Degree: Ⅱ Protection Grade: IP20 Mechanical Properties: Comply with IEC60068-2-6, IEC6008-2-27 Insulation Withstand: Comply with IEC61131-2 EMC Performance: Comply with IEC61131-2, IEC61000-4 Key Features / Technical Specifications: - Mandatory terminal module for system configuration - Stabilizes internal bus communication - Displays diagnostic information for network adapter and general diagnostics - Occupies one slot in the system - Current consumption: 26mA@5VDC - Installation: 35mm DIN-Rail - Dimensions: 119*14*80mm - Operating temperature (horizontal): -35℃~60℃ - Operating temperature (vertical): -35℃~50℃ - Storage temperature: -40℃~85℃ - Humidity: 5%~95%RH (no condensation) - Altitude: <2000m - Pollution degree: II - Protection grade: IP20 - Mechanical properties: IEC60068-2-6, IEC6008-2-27 compliant - Insulation withstand: IEC61131-2 compliant - EMC performance: IEC61131-2, IEC61000-4 compliant
