Rectangular stop unit KS-S1
Add to favorites
Compare this product
Characteristics
- Options
- rectangular
Description
Product description
The smooth stop module is designed for setups where the workpiece surface must remain unmarked. It is available in two sizes and mounts using one or two bolts. The short version can be oriented with either its long or short side against the workpiece for flexible positioning.
Features
Details (table)
Type | Size | Dimensions | STEP (3D)
KS-S1 | Small | PDF drawing available | STEP file available
KS-S2 | Wide | PDF drawing available | STEP file available
Technical specifications
The smooth stop module is designed for setups where the workpiece surface must remain unmarked. It is available in two sizes and mounts using one or two bolts. The short version can be oriented with either its long or short side against the workpiece for flexible positioning.
Features
- Non-marking smooth stop for delicate or finished workpieces
- Two sizes: KS-S1 (Small) and KS-S2 (Wide)
- Mounting with 1 or 2 bolts for adjustable fixation
- Short version usable with either long or short side against the workpiece
Details (table)
Type | Size | Dimensions | STEP (3D)
KS-S1 | Small | PDF drawing available | STEP file available
KS-S2 | Wide | PDF drawing available | STEP file available
Technical specifications
- Models: KS-S1 (Small), KS-S2 (Wide)
- Installation: 1 or 2 bolts
- Function: Smooth stop (non-marking)
- Documentation: PDF drawings and STEP files available for both models
