Penetrometer TG 63-150

penetrometer
penetrometer
Add to favorites
Compare this product


Description

Broad mobility Fitted on a hydraulic-tracked carriage, which allows you to move easily even on the most marshy terrain. It can even be positioned on very steep slopes; thanks to the three stabilisers and the possibility of tilting the mast, a perfect verticality is guaranteed to allow rod insertion. Anchoring system The semi-automatic anchoring system installed on the mast - necessary to obtain the required reaction during static tests - allows the operator to fix the machine in a few, intuitive and simple steps. It also reduces the insertion stress on the frame. Video training High energy efficiency Around 78% of the energy is transmitted to the rods. Can be used by a single operator High performance in a compact and easily transported penetrometer, which can be used even by a single operator. Drastically reduced test times, thanks to the semi-automatic anchoring system and the possibility of driving the rods and their liner tubes into the ground at the same time. Versatility Static tests can be carried out with Begemann bit (CPT), or with piezocone (CPTu) which can be implemented with the seismic module (S-CPTu). The hammer system for dynamic tests can be: Super Heavy (DPSH), Heavy (DPH) or Medium (DPM). The rotation head allows to drill some little pre-holes. Different types of samplers are also available to allow laboratory analysis of disturbed samples.

Catalogs

TG63-150
TG63-150
10 Pages
